CYDLGF4L6-60V is a high-performance double-level fuse terminal block with LED indication, designed for safe and efficient circuit protection in industrial control panels, automation systems, machine wiring, and electrical distribution applications. This terminal block combines a fuse disconnect terminal with feed-through connection, making it an ideal solution for protecting sensitive electrical circuits while saving panel space. It is widely used in PLC panels, industrial machinery, control cabinets, instrumentation systems, and automation circuits where circuit protection and clear fault indication are essential.
The key feature of CYDLGF4L6-60V is its built-in LED indication for 6–60V, which provides visual monitoring of fuse status and circuit operation. When the fuse is active and voltage is present, the LED indicates the circuit condition, helping technicians quickly identify faults or blown fuses during maintenance. This reduces troubleshooting time and improves safety in industrial electrical systems. The LED indication range of 6–60V makes it suitable for low-voltage control circuits, signal systems, and automation applications.
This terminal block is designed as a double-level fuse terminal, where the top level contains the fuse carrier and the bottom level provides a separate feed-through terminal connection. This design eliminates the need for additional terminal blocks, helping save DIN rail space and simplifying panel wiring. It accepts 5x20 mm and 5x25 mm cartridge fuses, providing reliable circuit protection for sensitive electrical equipment.
The CYDLGF4L6-60V uses a screw clamp connection system, ensuring strong conductor retention and vibration-resistant wiring. Screw terminals provide gas-tight and secure electrical contact, making them suitable for harsh industrial environments where reliability is critical. It supports wire sizes from 0.2 mm² to 4 mm² (24–10 AWG), making it compatible with a wide range of industrial control and power wiring applications.
Its compact 6 mm width makes it ideal for high-density panel installations where space-saving design is required. The terminal block is mounted on DIN 35 / DIN 35-15 rails, ensuring easy installation in industrial panels and switchboards. The side-entry wiring design improves cable routing and simplifies maintenance in compact electrical enclosures.
Manufactured from durable Polyamide (PA66) insulated housing, CYDLGF4L6-60V offers excellent electrical insulation, flame resistance, heat resistance, and mechanical strength. It is designed for continuous industrial operation and provides long service life even in demanding environments. With a rated voltage of 500V and 10A fuse current capacity, it delivers safe and reliable protection for industrial circuits.
| Specification | Details |
|---|---|
| Model Number | CYDLGF4L6-60V |
| Product Type | Double Level Fuse Terminal Block with LED |
| Connection Type | Screw Clamp |
| Rated Voltage | 500V |
| Voltage for LED Indication | 6–60V |
| Rated Current (Fuse) | 10A |
| Feed Through Current | 30A |
| Wire Size Range | 0.2 – 4 mm² |
| AWG Range | 24 – 10 AWG |
| Fuse Type | Cartridge Glass Fuse |
| Fuse Size | 5 x 20 mm / 5 x 25 mm |
| Number of Positions | 4 |
| Number of Levels | 2 |
| Terminal Width | 6 mm |
| Length | 94.5 mm |
| Height | 90.9 mm / 98.4 mm |
| Wire Entry Orientation | Side Entry |
| Mounting Type | DIN Rail Mount |
| DIN Rail Compatibility | DIN 35 / DIN 35-15 |
| Housing Material | Polyamide PA66 |
| Color | Grey |
| Stripping Length | 8–9 mm |
| Tightening Torque | 0.5 Nm |
| Rated Surge Voltage | 8 kV |
| Pollution Degree | 3 |
✔ Double-level fuse terminal design for compact wiring
✔ Built-in LED indication (6–60V) for fuse status monitoring
✔ Supports 5x20 mm / 5x25 mm cartridge fuse
✔ Screw clamp connection for secure wiring
✔ 6 mm slim design saves DIN rail space
✔ 500V rated voltage with 10A fuse protection
✔ 30A feed-through current capacity
✔ Durable Polyamide PA66 insulated housing
✔ Ideal for industrial control panels & automation systems
✔ Easy DIN rail mounting installation
CYDLGF4L6-60V is suitable for:
