CYG10 is a 10 sq.mm ground / earth terminal block designed for secure earthing and grounding connections in industrial electrical panels, switchboards, distribution boards, and automation systems. This terminal block is specially used for grounding wires and provides a safe path for fault current, helping improve electrical safety and equipment protection in industrial installations. The green-yellow color coding follows industry-standard earthing identification, making it easy to identify during panel wiring and maintenance.
The CYG10 terminal block uses a screw clamp connection system that ensures strong wire holding and vibration-resistant electrical contact. It supports conductor sizes up to 10 sq.mm, making it suitable for industrial grounding circuits where dependable electrical continuity is essential. Its feed-through grounding design helps maintain organized wiring and simplifies earthing distribution inside control panels. The compact body allows installation in space-saving electrical panel layouts while maintaining high safety standards.
Manufactured with high-grade polyamide insulated housing, CYG10 provides excellent heat resistance, insulation strength, and mechanical durability. It is designed for DIN rail mounting, making installation fast and maintenance convenient for panel builders, electricians, and industrial automation engineers. Because grounding connections are critical for equipment safety, the CYG10 terminal block is widely used in industrial machinery, power distribution systems, OEM panels, and process control applications where reliable earthing is required.
| Parameter | Specification |
|---|---|
| Product Code | CYG10 |
| Product Type | Ground / Earth Terminal Block |
| Rated Voltage | 1000 V |
| Rated Current | 57 A |
| Conductor Capacity | 0.2 – 10 mm² |
| AWG Range | 24 – 6 AWG |
| Connection Type | Screw Clamp |
| Screw Size | M4 |
| Tightening Torque | 1.2 Nm |
| Mounting Type | DIN 35 / DIN 35-15 Rail |
| Wire Entry Orientation | Side Entry |
| Housing Material | Polyamide |
| Rated Surge Voltage | 8 kV |
| Pollution Degree | 3 |
| Width | 10 mm |
| Length | 50 mm |
| Height (DIN 35x7.5 Rail) | 49 mm |
| Height (DIN 35x15 Rail) | 56.5 mm |
| Stripping Length | 11 mm |
| Color | Green / Yellow |
| Product Function | Ground / Earthing Feed Through |
CYG10 is commonly used in:
