CYG16 is a 16 sq.mm ground / earth terminal block designed for secure earthing and grounding connections in industrial electrical panels, switchboards, automation systems, PLC panels, and power distribution applications. This terminal block is specially engineered to provide a safe path for fault current, helping protect electrical equipment, operators, and industrial systems from leakage current and electrical faults. The green-yellow color coding follows standard industrial earthing identification, making grounding circuits easy to identify during installation, maintenance, and troubleshooting.
The CYG16 terminal block uses a screw clamp connection system that ensures strong wire holding and dependable electrical continuity in grounding applications. It supports conductor sizes up to 16 sq.mm, making it suitable for industrial grounding systems, machine control panels, OEM electrical assemblies, switchgear panels, and heavy-duty power distribution installations. Its compact DIN rail mountable design allows electricians and panel builders to create organized grounding circuits while saving panel space.
Manufactured from high-grade polyamide insulating housing, the CYG16 provides excellent thermal resistance, mechanical strength, and electrical insulation performance. The grounding connection is made directly to the DIN rail, ensuring a low-resistance and secure earthing path. Its rugged construction allows long service life in demanding industrial environments where vibration, heat, and mechanical stress are common. This makes CYG16 a dependable solution for electrical safety and industrial grounding applications.
Because of its robust screw clamp design, reliable grounding performance, and easy installation, the CYG16 is widely used by electricians, panel builders, automation engineers, OEM manufacturers, and industrial maintenance teams in professional electrical installations where safe earthing is essential.
| Parameter | Specification |
|---|---|
| Product Code | CYG16 |
| Product Type | Ground / Earth Terminal Block |
| Color | Green / Yellow |
| Rated Voltage | 1000 V |
| Rated Current | 76 A |
| Conductor Capacity | 1.5 – 16 mm² |
| Connection Type | Screw Clamp |
| Screw Size | M4 |
| Tightening Torque | 1.2 Nm |
| Mounting Type | DIN 35 / DIN 35-15 Rail |
| Wire Entry Orientation | Side Entry |
| Housing Material | Polyamide |
| Rated Surge Voltage | 8 kV |
| Pollution Degree | 3 |
| Width | 12 mm |
| Length | 58.9 mm |
| Height (DIN 35x7.5 Rail) | 50.8 mm |
| Height (DIN 35x15 Rail) | 58.5 mm |
| Stripping Length | 12 mm |
| Product Function | Ground / Earthing Terminal Block |
CYG16 is commonly used in:
