CYG2.5 is a 2.5 sq.mm ground / earth terminal block specially designed for safe and reliable earthing connections in industrial electrical systems. It is used in control panels, automation cabinets, switchboards, PLC panels, machinery wiring, and power distribution systems where proper grounding is essential for equipment safety and fault current protection.
A grounding terminal block plays a critical role in industrial electrical installations by creating a secure low-resistance path for leakage current or fault current, helping protect electrical equipment, operators, and connected systems. The CYG2.5 is designed to provide dependable grounding performance while maintaining organized panel wiring and safe earthing distribution.
The terminal block features a green-yellow insulated housing, which follows standard industrial color coding for earth / grounding circuits. This color identification helps electricians and maintenance engineers quickly identify grounding points during installation, inspection, servicing, and troubleshooting, improving electrical safety and reducing maintenance time.
The CYG2.5 uses a screw clamp connection mechanism, which ensures firm conductor clamping and stable electrical contact. This provides dependable grounding continuity and reduces the risk of loose conductor connections in industrial operating conditions. The compact DIN rail mounting design makes it suitable for modern control panels where panel space optimization and organized grounding arrangements are required.
Manufactured from high-strength flame-retardant polyamide insulating material, the CYG2.5 offers excellent thermal resistance, insulation safety, and mechanical durability. The grounding connection is directly made to the DIN rail, creating a secure and efficient earthing path.
Because of its compact design, safe grounding performance, easy installation, and durable industrial construction, the CYG2.5 is widely used in industrial automation, machine control systems, switchgear panels, OEM electrical assemblies, instrumentation systems, and process control applications where reliable earthing is essential.
| Parameter | Specification |
|---|---|
| Product Code | CYG2.5 |
| Product Type | Ground / Earth Terminal Block |
| Color | Green / Yellow |
| Rated Voltage | 800 V |
| Rated Current | 24 A |
| Conductor Capacity | 0.2 – 2.5 mm² |
| AWG Range | 24 – 12 AWG |
| Connection System | Screw Clamp |
| Mounting Style | DIN 35 / DIN 35-15 Rail |
| Wire Entry | Side Entry |
| Screw Size | M3 |
| Tightening Torque | 0.5 Nm |
| Housing Material | Flame Retardant Polyamide |
| Rated Surge Voltage | 8 kV |
| Pollution Degree | 3 |
| Electrical Function | Ground / Earthing Terminal |
CYG2.5 is commonly used in:
Provides a secure path for fault current and leakage protection.
Green-yellow housing clearly identifies grounding terminals.
Screw clamp system ensures stable grounding continuity.
Small DIN rail body saves space in electrical panels.
Built for heat resistance and long-term industrial use.
Supports safe maintenance and reliable grounding performance.
