CYG4/3 is a three-level ground / earth terminal block specially designed for industrial electrical systems where compact grounding distribution, organized earth circuit management, and secure protective earthing connections are essential. In modern electrical control panels, PLC cabinets, switchboards, machine control systems, and automation assemblies, multiple grounding points are often required in limited DIN rail space. Using standard single-level earth terminals in such installations can consume more panel space and make grounding layouts crowded.
The CYG4/3 solves this problem by integrating three grounding connection levels in one compact terminal block, allowing multiple earth conductors to be connected vertically while maintaining a structured and organized grounding system. This makes it ideal for high-density industrial panels where several grounding circuits need to be managed efficiently.
The green-yellow housing follows standard industrial earth circuit color coding, making grounding points instantly recognizable for electricians and maintenance engineers.
The CYG4/3 works as a multi-level grounding terminal block, where conductors are connected through three separate earth connection levels inside one insulated body.
Its functional design provides:
The screw clamp conductor connection system securely holds earth conductors and creates a dependable grounding continuity through the DIN rail, ensuring safe fault current discharge in electrical systems.
This design improves earthing circuit density while saving valuable panel space.
The green-yellow housing provides quick visual identification of grounding circuits inside electrical panels.
Safety advantages include:
Color-coded grounding terminals improve electrical safety and maintenance accuracy.
Green-yellow terminals are standard for protective earthing applications.
Benefits include:
This improves safety in industrial grounding systems.
The CYG4/3 is manufactured using flame-retardant engineering polyamide insulation with industrial-grade grounding hardware, designed for demanding industrial electrical environments.
Construction advantages include:
Its rugged design ensures dependable protective grounding performance.
Using CYG4/3 improves grounding system layout by combining multiple earth points into one compact terminal block.
Benefits include:
| Parameter | Specification |
|---|---|
| Product Code | CYG4/3 |
| Product Type | Three-Level Ground / Earth Terminal Block |
| Color | Green / Yellow |
| Connection System | Screw Clamp |
| Number of Levels | 3 Tier |
| Rated Voltage | 800 V |
| Rated Current | 32 A |
| Conductor Capacity | 0.2 – 4 mm² |
| AWG Range | 24 – 10 AWG |
| Mounting Style | DIN Rail |
| Wire Entry | Side Entry |
| Housing Material | Flame Retardant Polyamide |
| Rated Surge Voltage | 8 kV |
| Pollution Degree | 3 |
| Electrical Function | Ground / Earthing Terminal |
| Installation Type | Screw Tightening |
| Mechanical Strength | High |
| Industrial Use | PLC Panels, Automation Systems, Switchboards |
Three grounding levels support compact earth circuit distribution.
Reduces DIN rail usage in compact electrical cabinets.
Green-yellow housing supports quick visual recognition.
Screw clamp design ensures stable earth conductor contact.
Built for demanding grounding applications.
Organized grounding layout improves servicing efficiency.
Creates structured and safe earth circuit layouts.
CYG4/3 is widely used in:
