CYG4/4 is a four-level ground / earth terminal block specifically engineered for industrial electrical systems where multiple grounding points, compact DIN rail installation, and efficient protective earthing distribution are required in limited panel space. In modern electrical control panels, PLC cabinets, industrial automation systems, machine control assemblies, and switchboards, several earth conductors often need to be connected securely within a compact grounding layout.
Using standard single-level earth terminals in such applications increases DIN rail usage and creates crowded grounding arrangements. The CYG4/4 solves this issue by integrating four independent earth connection levels in one compact terminal body, allowing multiple protective grounding circuits to be connected vertically while saving valuable panel space.
Its green-yellow housing follows international industrial earthing identification standards, helping technicians instantly identify protective earth circuits during installation, servicing, and maintenance.
This terminal block is highly suitable for industrial electrical applications where high-density grounding, safe fault current discharge, and structured earth circuit management are essential.
The CYG4/4 operates as a four-level protective earth terminal block, allowing conductors to be connected through four independent grounding levels inside one compact housing.
Its functional design provides:
The screw clamp conductor connection mechanism securely locks each conductor and creates dependable grounding continuity through the DIN rail, ensuring safe leakage and fault current transfer in industrial electrical systems.
This design improves grounding density while maintaining safe and organized panel wiring.
The green-yellow body color provides immediate visual identification of protective earth circuits inside electrical panels.
Safety advantages include:
Color-coded earth terminals improve safety and maintenance efficiency.
The four-level grounding design offers several industrial advantages.
Benefits include:
This makes CYG4/4 ideal for compact industrial earthing systems.
The CYG4/4 is manufactured using flame-retardant engineering polyamide insulation with industrial-grade grounding hardware, designed for demanding electrical environments.
Construction advantages include:
Its rugged construction ensures dependable protective grounding performance in industrial applications.
Using CYG4/4 improves panel grounding layout by combining multiple earth circuits into one compact terminal assembly.
Benefits include:
| Parameter | Specification |
|---|---|
| Product Code | CYG4/4 |
| Product Type | Four-Level Ground / Earth Terminal Block |
| Color | Green / Yellow |
| Connection System | Screw Clamp |
| Number of Levels | 4 Level |
| Rated Voltage | 800 V |
| Rated Current | 32 A |
| Conductor Capacity | 0.2 – 4 mm² |
| AWG Range | 24 – 10 AWG |
| Mounting Style | DIN Rail |
| Wire Entry | Side Entry |
| Housing Material | Flame Retardant Polyamide |
| Rated Surge Voltage | 8 kV |
| Pollution Degree | 3 |
| Electrical Function | Ground / Earthing Terminal |
| Installation Type | Screw Tightening |
| Mechanical Strength | High |
| Industrial Use | PLC Panels, Automation Systems, Switchboards |
Supports compact multi-point earthing distribution.
Reduces DIN rail usage in electrical cabinets.
Green-yellow housing supports quick visual recognition.
Screw clamp design ensures stable earth conductor contact.
Built for demanding industrial grounding applications.
Improves servicing and troubleshooting efficiency.
Creates safe and organized earth circuit layouts.
CYG4/4 is widely used in:
