CYG6 is a 6 sq.mm ground / earth terminal block specially designed for industrial electrical systems where safe protective grounding, fault current discharge, and secure earth conductor termination are essential. In electrical control panels, switchboards, PLC cabinets, automation systems, machine control panels, and power distribution assemblies, grounding plays a critical role in protecting electrical equipment and personnel from leakage current, insulation faults, and accidental electrical hazards.
The CYG6 is used to create a low-resistance grounding path, allowing fault current to safely discharge to earth instead of damaging equipment or creating dangerous voltage conditions. It acts as a dedicated protective earth connection point for grounding conductors in industrial electrical installations.
Its green-yellow housing follows standard industrial earthing identification, helping technicians quickly recognize protective earth circuits during installation, maintenance, and troubleshooting.
This terminal block is ideal for industrial applications where safe grounding continuity, organized earth circuit management, and reliable protective earthing are critical.
The CYG6 operates as a DIN rail mounted protective earth terminal block, where conductors are securely clamped and grounding continuity is transferred through the DIN rail grounding path.
Its working design provides:
The screw clamp conductor locking system securely holds the grounding conductor and ensures dependable grounding contact even in vibration-prone industrial environments.
This creates a safe and structured protective grounding solution.
The green-yellow housing provides immediate visual recognition of protective earth circuits.
Safety advantages include:
Color-coded grounding terminals improve electrical panel safety.
Green-yellow terminal blocks are internationally used for protective grounding applications.
Benefits include:
This improves structured grounding systems in industrial panels.
The CYG6 is manufactured using flame-retardant engineering polyamide insulation with industrial-grade conductive grounding hardware, designed for demanding industrial electrical environments.
Construction advantages include:
Its rugged construction ensures dependable protective earthing performance.
Using CYG6 improves grounding layout by creating a dedicated earth conductor connection point.
Benefits include:
| Parameter | Specification |
|---|---|
| Product Code | CYG6 |
| Product Type | Ground / Earth Terminal Block |
| Color | Green / Yellow |
| Rated Voltage | 800 V |
| Rated Current | 41 A |
| Conductor Capacity | 0.2 – 6 mm² |
| AWG Range | 24 – 8 AWG |
| Connection System | Screw Clamp |
| Mounting Style | DIN 35 / DIN 35-15 Rail |
| Wire Entry | Side Entry |
| Screw Size | M3 |
| Tightening Torque | 0.8 Nm |
| Housing Material | Flame Retardant Polyamide |
| Rated Surge Voltage | 8 kV |
| Pollution Degree | 3 |
| Electrical Function | Ground / Earthing Terminal |
| Installation Type | Screw Tightening |
| Mechanical Strength | High |
| Industrial Use | PLC Panels, Switchboards, Automation Systems |
Provides safe fault current discharge and equipment protection.
Green-yellow housing supports quick visual recognition.
Screw clamp design ensures stable earth conductor contact.
Suitable for 6 sq.mm industrial grounding applications.
Built for long-term industrial use.
Improves troubleshooting and servicing efficiency.
Creates safe and organized earthing layouts.
CYG6 is widely used in:
