The DB16R 16 sq.mm Compact Distribution Terminal Block is a high-performance electrical distribution component designed for safe, organized, and efficient power distribution in industrial and commercial electrical systems. This compact modular distribution block is specially developed to simplify wiring connections inside electrical panels, switchboards, distribution boards, and automation systems. It provides a secure way to distribute electrical power from a single input source to multiple output connections while maintaining reliability and safety in demanding applications.
This distribution terminal block features a compact space-saving design that allows easy installation in electrical enclosures where panel space is limited. Its modular construction improves wiring organization and reduces cable clutter, making panel maintenance and troubleshooting easier. With high current carrying capacity and excellent insulation properties, DB16R is suitable for professional panel builders, electricians, industrial automation systems, and commercial electrical installations.
In electrical systems, proper power distribution is essential for maintaining system efficiency and safety. The DB16R Compact Distribution Terminal Block is designed to distribute electrical power from 1 input connection to 6 output connections, allowing organized and reliable current distribution from a single incoming power source. This makes it an ideal solution for single-phase power distribution systems used in industrial and commercial applications.
With a rated current of 76A and rated voltage of 1000V, DB16R is capable of handling demanding electrical loads while ensuring stable performance. It helps reduce wiring complexity inside electrical panels by eliminating unnecessary cable junctions and providing a centralized distribution point. This improves overall electrical safety and makes installations cleaner and more professional.
DB16R is manufactured using a durable polyamide insulated housing, known for its excellent electrical insulation, mechanical strength, heat resistance, and long service life. The strong housing material provides protection against electrical stress, environmental factors, and mechanical wear, ensuring dependable long-term performance in industrial conditions.
Its compact modular body design helps save valuable panel space while maintaining proper wire termination spacing for secure electrical connections. The side-entry wire connection system allows easy cable insertion and simplifies wiring work inside control panels and switchgear assemblies. This makes installation faster and more efficient for technicians and panel builders.
The DB16R distribution block is designed for quick and easy installation inside electrical panels. It supports DIN 32, DIN 35, and DIN 35-15 rail mounting, making it compatible with standard industrial panel mounting systems. This DIN rail compatibility allows fast installation, easy removal, and simplified maintenance when panel modifications are required.
The block uses screw clamp connection technology, which provides tight and secure conductor fastening. The screw-operated design ensures vibration-resistant electrical connections, reducing the chances of loose wires and overheating during operation. This improves overall electrical reliability in demanding industrial environments.
Safety is one of the most important requirements in power distribution systems, and DB16R is built to deliver reliable insulation and secure electrical performance. It comes with a rated surge voltage of 6KV, helping protect electrical systems from voltage spikes and transient disturbances. The pollution degree 3 rating makes it suitable for industrial electrical environments where dust, humidity, or contaminants may be present.
The input tightening torque of 1.2 Nm and output tightening torque of 0.8 Nm ensure proper cable fastening for safe current flow and reduced resistance at connection points. Secure termination helps prevent overheating, arcing, and voltage loss during long-term operation.
The DB16R Compact Distribution Terminal Block is widely used in various electrical and industrial applications, such as:
Its compact design and reliable power handling capability make it an excellent choice for professional electrical applications where safe and organized power distribution is required.
| Specification | Details |
|---|---|
| Model Number | DB16R |
| Product Type | Compact Distribution Terminal Block |
| Rated Voltage | 1000V |
| Rated Current | 76A |
| Input Connection | 1 Input |
| Output Connections | 6 Outputs |
| Input Cable Size | 6 – 16 sq.mm |
| Output Cable Size | 2.5 – 6 sq.mm |
| Housing Material | Polyamide |
| Color | Red |
| Mounting Type | DIN Rail Mounting |
| DIN Rail Compatibility | DIN 32 / DIN 35 / DIN 35-15 |
| Wire Entry | Side Entry |
| Screw Size | M5 |
| Rated Surge Voltage | 6KV |
| Pollution Degree | 3 |
| Length | 66 mm |
| Height | 57.5 mm |
| Width | 27 mm |
| Applications | Control Panels, Distribution Boards, Switchgear, Industrial Panels |
