A key advantage of this compact distribution block is its space-saving modular body design. In modern electrical enclosures, panel space is often limited and requires compact components that provide maximum functionality in minimal space. The DB16Y is designed to occupy less installation space while still offering efficient multi-output power distribution capability. This helps improve panel layout and makes wiring systems more accessible and organized.
The body of the DB16Y Compact Distribution Terminal Block is manufactured using high-quality polyamide insulated housing, which offers excellent electrical insulation, heat resistance, impact strength, and long service life. Polyamide construction provides strong protection for conductive parts and improves safety during electrical operation. It also ensures reliable performance in industrial working environments where temperature changes and mechanical stress are common.
Its side-entry wire connection design allows easy cable insertion and helps create organized cable routing inside electrical panels. This improves wiring convenience for electricians and reduces installation complexity. The secure screw clamp connection system provides tight conductor fastening, helping reduce the chances of loose wiring, overheating, voltage drop, or electrical faults during long-term operation.
The DB16Y is designed for DIN rail mounting, making installation simple and compatible with standard industrial electrical panel systems. It supports DIN 32, DIN 35, and DIN 35-15 rail systems, allowing quick installation, easy replacement, and convenient maintenance when required. DIN rail mounting improves component organization and reduces panel assembly time in professional installations.
Electrical safety is an important feature of the DB16Y. It comes with a rated surge voltage of 6KV, which helps protect electrical circuits from voltage spikes and transient disturbances. Its secure screw clamp design, strong insulation housing, and reliable electrical continuity improve overall safety and long-term performance in demanding industrial environments.
The DB16Y Compact Distribution Terminal Block is commonly used in:
Its compact design, reliable power distribution capability, strong insulation housing
| Specification | Details |
|---|---|
| Model Number | DB16Y |
| Product Type | Compact Distribution Terminal Block |
| Rated Voltage | 1000V |
| Rated Current | 76A |
| Input Connection | 1 Input |
| Output Connections | 6 Outputs |
| Input Cable Size | 6 – 16 sq.mm |
| Output Cable Size | 2.5 – 6 sq.mm |
| Housing Material | Polyamide |
| Color | Yellow |
| Mounting Type | DIN Rail Mounting |
| DIN Rail Compatibility | DIN 32 / DIN 35 / DIN 35-15 |
| Wire Entry | Side Entry |
| Screw Size | M5 |
| Rated Surge Voltage | 6KV |
| Pollution Degree | 3 |
| Length | 66 mm |
| Height | 57.5 mm |
| Width | 27 mm |
| Applications | Control Panels, Distribution Boards, Switchgear, Industrial Panels |
✅ Compact space-saving modular design
✅ Efficient 1 input to 6 output power distribution
✅ High 76A current carrying capacity
✅ Supports 1000V rated voltage
✅ Strong insulated polyamide housing
✅ Easy DIN rail mounting installation
✅ Secure screw clamp wire connection
✅ Reduces panel wiring complexity
✅ Improves electrical safety and reliability
✅ Suitable for industrial and commercial applications
✅ Easy maintenance and organized cable management
✅ Long-lasting durable construction
