The DB35 35 sq.mm Compact Distribution Terminal Block is a high-capacity electrical power distribution solution designed for industrial, commercial, and control panel applications where safe and organized power distribution is essential. It is specially engineered to distribute electrical power from one incoming source to multiple outgoing circuits in a secure and structured way, helping reduce wiring complexity and improve electrical panel efficiency. This compact distribution block is widely used in switchgear systems, electrical distribution boards, automation panels, machine control systems, and industrial power distribution applications where dependable electrical performance is required.
In modern electrical systems, safe and organized power distribution is one of the most important requirements for maintaining system reliability and reducing panel wiring complexity. Traditional wiring methods often involve multiple branch joints and cable connections, which can create cluttered electrical panels and make maintenance difficult. The DB35 Compact Distribution Terminal Block solves this issue by providing a centralized power distribution point where one incoming supply can be safely distributed to multiple outgoing circuits. This improves cable management, reduces wiring congestion, and creates a cleaner professional panel installation.
One of the key advantages of the DB35 Distribution Terminal Block is its 1 input and 6 output connection design, allowing one main incoming power source to distribute electrical current safely to multiple outgoing branch circuits. This modular distribution arrangement reduces unnecessary cable joints and improves wiring organization inside electrical panels. It also helps electricians and panel builders save installation time while creating organized and easy-to-maintain electrical systems.
The DB35 is designed for high-performance electrical applications and supports a rated voltage of 1000V with a rated current of 125A, making it suitable for industrial and commercial systems where safe power transfer and stable electrical flow are essential. Its high current carrying capability makes it ideal for switchgear systems, industrial control panels, machine wiring systems, and heavy-duty power distribution applications requiring reliable performance.
A major feature of this compact distribution block is its 35 sq.mm conductor capacity, allowing secure connection of larger power conductors for heavy-duty electrical applications. This makes it a reliable solution for installations where higher electrical loads need to be distributed safely across multiple circuits. Its modular construction improves current distribution efficiency and supports professional industrial panel building applications.
The body of the DB35 Compact Distribution Terminal Block is manufactured using high-quality polyamide insulated housing, which offers excellent electrical insulation, heat resistance, impact strength, and long service life. This strong insulated housing protects conductive parts from accidental contact and improves electrical safety during operation. Polyamide construction also ensures reliable performance in industrial environments exposed to temperature changes and mechanical stress.
Its side-entry wire connection design allows convenient cable insertion and organized cable routing inside electrical panels. This feature reduces wiring complexity and improves installation convenience, especially in compact electrical enclosures. The secure screw clamp connection system provides strong conductor fastening and reliable electrical contact, reducing the risk of loose wiring, overheating, voltage drop, or electrical faults during long-term use.
The DB35 supports DIN rail as well as panel mounting, making installation flexible and suitable for standard industrial electrical panel systems. DIN rail mounting improves component organization, reduces installation time, and makes maintenance easier when required. This mounting flexibility makes the distribution block suitable for professional electrical panel building applications where versatility is important.
Electrical safety is an important requirement in power distribution systems, and the DB35 is designed with a rated surge voltage of 6KV and pollution degree 3, making it suitable for industrial environments exposed to voltage disturbances, dust, or contaminants. These safety features improve system reliability and support safe long-term operation in demanding industrial applications.
The DB35 Compact Distribution Terminal Block is commonly used in:
| Specification | Details |
|---|---|
| Model Number | DB35 |
| Product Type | Compact Distribution Terminal Block |
| Rated Voltage | 1000V |
| Rated Current | 125A |
| Input Connection | 1 Input |
| Output Connections | 6 Outputs |
| Input Cable Size | 6 – 35 sq.mm |
| Output Cable Size | 2.5 – 16 sq.mm |
| Housing Material | Polyamide |
| Color | Grey |
| Mounting Type | DIN Rail / Panel Mounting |
| DIN Rail Compatibility | DIN 32 / DIN 35 / DIN 35-15 |
| Wire Entry | Side Entry |
| Screw Size | M8 |
| Input Tightening Torque | 6 Nm |
| Output Tightening Torque | 3 Nm |
| Rated Surge Voltage | 6KV |
| Pollution Degree | 3 |
| Length | 74.4 mm |
| Width | 27 mm |
| Applications | Control Panels, Distribution Boards, Switchgear |
✅ Compact space-saving modular design
✅ Efficient 1 input to 6 output power distribution
✅ High 125A current carrying capacity
✅ Supports 1000V rated voltage
✅ Suitable for 35 sq.mm conductor connection
✅ Strong insulated polyamide housing
✅ Easy DIN rail and panel mounting installation
✅ Secure screw clamp wire connection
✅ Reduces panel wiring complexity
✅ Improves electrical safety and reliability
✅ Suitable for industrial and commercial applications
✅ Long-lasting durable construction
