Product Description

The DB35R 35 sq.mm Compact Distribution Terminal Block is a heavy-duty electrical power distribution solution designed for industrial, commercial, and control panel applications where safe and organized power distribution is essential. It is specially engineered to distribute electrical power from one incoming source to multiple outgoing circuits in a secure and structured way, helping reduce wiring complexity and improve electrical panel efficiency. This compact distribution block is widely used in switchgear systems, electrical distribution boards, automation panels, machine control systems, and industrial power distribution applications where dependable electrical performance and long-term safety are required.

In modern electrical systems, proper power distribution is one of the most important requirements for maintaining panel safety, reducing cable clutter, and simplifying maintenance. Traditional branch wiring methods often require multiple cable joints and wire branching, which can make electrical panels congested and difficult to manage. The DB35R Compact Distribution Terminal Block solves this problem by providing a centralized power distribution point where one incoming supply can be safely distributed to multiple outgoing circuits. This creates a cleaner wiring layout, improves cable management, and supports professional electrical panel installation.

One of the key advantages of the DB35R Distribution Terminal Block is its 1 input and 6 output connection design, allowing one main incoming power source to distribute electrical current safely to multiple outgoing branch circuits. This modular distribution arrangement reduces unnecessary cable joints and improves wiring organization inside electrical panels. It also saves installation time and helps electricians and panel builders create structured and easy-to-maintain electrical systems for industrial applications.

The DB35R is designed for high-performance electrical applications and supports a rated voltage of 1000V with a rated current of 125A, making it suitable for industrial and commercial systems where safe power transfer and stable electrical flow are essential. Its high current carrying capability makes it ideal for switchgear systems, industrial control panels, machine wiring systems, and heavy-duty power distribution applications requiring reliable performance under demanding operating conditions.

A major feature of this compact distribution block is its 35 sq.mm conductor capacity, allowing secure connection of larger power conductors for heavy-duty electrical applications. This makes it a dependable solution for installations where higher electrical loads need to be distributed safely across multiple circuits. Its modular construction improves current distribution efficiency while maintaining safe conductor termination in industrial power systems.

The body of the DB35R Compact Distribution Terminal Block is manufactured using high-quality polyamide insulated housing, which offers excellent electrical insulation, heat resistance, impact strength, and long service life. This strong insulated housing protects conductive parts from accidental contact and improves electrical safety during operation. Polyamide construction also ensures reliable performance in industrial environments exposed to temperature changes, mechanical stress, and continuous operation.

Its side-entry wire connection design allows convenient cable insertion and organized cable routing inside electrical panels. This feature reduces wiring complexity and improves installation convenience, especially in compact electrical enclosures. The secure screw clamp connection system provides strong conductor fastening and reliable electrical contact, reducing the risk of loose wiring, overheating, voltage drop, or electrical faults during long-term use.

The DB35R supports DIN rail as well as panel mounting, making installation flexible and suitable for standard industrial electrical panel systems. DIN rail mounting improves component organization, reduces installation time, and makes maintenance easier when required. This mounting flexibility makes the distribution block suitable for professional electrical panel building applications where versatility and safe installation are important.

Electrical safety is a critical requirement in power distribution systems, and the DB35R is designed with a rated surge voltage of 6KV and pollution degree 3, making it suitable for industrial environments exposed to voltage disturbances, dust, or contaminants. These safety features improve system reliability and support safe long-term operation in demanding industrial applications.
