3VJ10 MCCB, Thermal Magnetic Trip Unit - 3VJ1092-3DB32-0AA0

Product Description

Siemens 3VJ10 MCCB, Thermal Magnetic Trip Unit – 3VJ1092-3DB32-0AA0

The Siemens 3VJ1092-3DB32-0AA0 is a SENTRON 3VJ10 series Molded Case Circuit Breaker (MCCB) designed for reliable protection of low-voltage electrical distribution systems against overload and short-circuit faults. This 3-pole MCCB is equipped with a Thermal Magnetic Trip Unit (ATFM type), providing adjustable overload protection and fixed short-circuit protection for industrial and commercial applications.

It is commonly used in LT panels, MCC/PCC systems, motor feeder circuits, industrial distribution boards, and infrastructure power networks, where dependable protection and compact installation are essential.

Key Features:

• Siemens SENTRON 3VJ10 series MCCB

• Part Number: 3VJ1092-3DB32-0AA0

• 3-pole molded case circuit breaker

• Thermal Magnetic Trip Unit (ATFM type)

• Rated current: 25A

• Frame size: 3VJ10, 125A frame

• Adjustable overload protection: Ir = 20A–25A

• Fixed short-circuit protection: Ii ≈ 500A

• Breaking capacity: 25kA at 415V AC

• High reliability for feeder and distribution protection

• Compact and rugged industrial design

• Screw terminal connection

• Suitable for industrial and commercial electrical systems

• Complies with IEC 60947-2 standards
