Siemens SENTRON 3VJ MCCB 4P 63A 36kA Molded Case Circuit Breaker – 3VJ1106-5EB42-0AA0
The Siemens 3VJ1106-5EB42-0AA0 is a high-performance SENTRON 3VJ Molded Case Circuit Breaker (MCCB) designed to provide reliable protection against overloads and short circuits in low-voltage electrical distribution systems. This 4 Pole MCCB features a rated current of 63A and a breaking capacity of 36kA at 415V AC, ensuring dependable protection for industrial, commercial, and infrastructure applications. Equipped with an Adjustable Thermal Magnetic Trip Unit (ATFM), it offers precise overload and short-circuit protection while maintaining operational safety and system reliability. Its compact design, robust construction, and screw terminal connections make it ideal for LT panels, distribution boards, motor control centers, and power distribution networks.
• Siemens SENTRON 3VJ series MCCB
• Part Number: 3VJ1106-5EB42-0AA0
• 4 Pole (4P) configuration
• Rated current: 63A
• Frame size: 125A
• Breaking capacity: 36kA at 415V AC
• Adjustable Thermal Magnetic Trip Unit (ATFM)
• Adjustable overload protection (Ir: 50.4A to 63A)
• Short-circuit protection (Ii: 10 × In)
• Reliable overload and short-circuit protection
• Compact and rugged industrial design
• Screw terminal connection
• Front connection arrangement
• High mechanical and electrical endurance
• Suitable for industrial and commercial power distribution
• Easy installation and maintenance
• Designed according to IEC standards
• Ideal for LT panels, MCC, PCC, and distribution boards
| Parameter | Specification |
|---|---|
| Product Series | Siemens SENTRON 3VJ |
| Part Number | 3VJ1106-5EB42-0AA0 |
| Product Type | Molded Case Circuit Breaker (MCCB) |
| Number of Poles | 4 Pole (4P) |
| Rated Current (In) | 63A |
| Frame Size | 125A |
| Breaking Capacity (Icu) | 36kA at 415V AC |
| Service Breaking Capacity (Ics) | 75% of Icu |
| Trip Unit Type | Adjustable Thermal Magnetic (ATFM) |
| Overload Protection (Ir) | 50.4A – 63A |
| Short Circuit Protection (Ii) | 10 × In |
| Rated Operational Voltage | Up to 690V AC |
| Frequency | 50/60 Hz |
| Connection Type | Screw Terminal Connection |
| Mounting Type | Panel Mounting |
| Connection Arrangement | Front Connection |
| Protection Function | Overload & Short Circuit Protection |
| Degree of Protection | IP42 (Front) |
| Standard Compliance | IEC Standards |
| Country of Origin | India |
| Application | LT Panels, MCC Panels, PCC Panels, Distribution Boards, Industrial Power Distribution Systems |
