Product Description

Siemens 3WT8165-6AG08-5BC2 – Air Circuit Breaker (ACB)

The Siemens 3WT8165-6AG08-5BC2 is a SENTRON 3WT8 series Air Circuit Breaker (ACB) used for high-capacity low-voltage power distribution systems in PCC, MCC, transformer and generator panels.

It belongs to the 1600A frame (3WT8165 family) and is designed for industrial-grade fault protection with high short-circuit breaking capacity (typically up to 66 kA class at 500V AC depending on configuration).

🔹 Description

The Siemens 3WT8165-6AG08-5BC2 is a draw-out type ACB (Air Circuit Breaker) used for protecting and controlling large electrical systems. It provides protection against:

• Overload conditions
• Short-circuit faults
• Earth faults (depending on trip unit configuration)

It uses an electronic microprocessor-based trip unit (ETU37WT family) for precise and adjustable protection settings.

👉 Simple meaning:
Ye 1600A class ka industrial main breaker hai jo heavy fault current ko safely isolate karta hai aur system ko protect karta hai.

🔹 Key Features

• Siemens SENTRON 3WT8 series ACB
• Model: 3WT8165-6AG08-5BC2
• Frame size: 3WT8165 (1600A class)
• Type: Air Circuit Breaker (ACB)
• Configuration: 3 Pole / 4 Pole variant (depending on build)
• Breaking capacity: Up to 66 kA @ 500V AC (variant dependent)
• Type: Withdrawable (draw-out) design
• Trip unit: ETU37WT LSING (microprocessor-based)
• Protection functions:
  • Overload protection
  • Short-circuit protection
  • Earth fault protection (variant dependent)
• Motor/manual operating mechanism (variant dependent)
• Auxiliary contacts + interlock support
• IEC 60947-2 compliant design
• High mechanical endurance for industrial switching
