Siemens 5SL5225-7RC MCB 25A 2-Pole C Characteristic 10kA DC

The Siemens 5SL5225-7RC is a SENTRON 5SL5 miniature circuit breaker (MCB) designed specifically for DC circuit protection. This Siemens DC MCB features a 25 A rated current, 2-pole configuration, C tripping characteristic, 440 V DC operating voltage and 10 kA short-circuit breaking capacity. It is intended for electrical systems where dependable protection against overload and short-circuit conditions is required in DC applications.

The Siemens 5SL5225-7RC 25A 2-pole DC MCB is suitable for appropriately designed DC distribution and control circuits. Unlike a conventional AC-only miniature circuit breaker, the Siemens 5SL5 DC range is designed for the specific requirements of DC fault interruption, making it suitable for selected industrial DC systems, control circuits, battery applications, power electronics and other compatible DC installations.

The 2-pole configuration provides coordinated protection and switching for compatible DC circuits. This makes the device suitable for electrical panels where two poles need to be protected or switched according to the system design. Correct pole arrangement and wiring are especially important in DC applications because DC fault arcs do not naturally extinguish at a zero crossing as they do in AC systems.

With a 25 A rated current, the 5SL5225-7RC is suitable for medium-current DC circuits where the connected load, conductor capacity and protection requirements match the MCB rating. Proper coordination with upstream and downstream protective equipment is essential for reliable operation.

The C tripping characteristic provides a defined response for suitable circuits with moderate starting or transient currents. It can be considered for compatible DC loads where the expected operating and startup current profile is appropriate for the selected characteristic.

The 10 kA short-circuit breaking capacity provides the specified fault-interruption capability for applicable DC protection arrangements. Before installation, the prospective short-circuit current should be assessed to ensure the MCB is suitable for the actual fault level.

Key Features

• Siemens 5SL5225-7RC
• SENTRON 5SL5 series DC miniature circuit breaker
• Rated current: 25 A
• 2-pole (2P) configuration
• C tripping characteristic
• 10 kA short-circuit breaking capacity
• Maximum operating voltage: 440 V DC
• Designed specifically for DC circuit protection
• Provides overload protection
• Provides short-circuit protection
• Suitable for compatible DC distribution systems
• Suitable for industrial DC control panels
• Suitable for battery and energy-related applications
• Suitable for power-electronics installations
• Suitable for OEM electrical equipment
• Compact modular circuit protection solution

Applications

The Siemens 5SL5225-7RC 25A 2-pole C curve DC MCB can be considered for:

• DC electrical distribution
• Industrial DC control panels
• Battery systems
• Energy storage applications
• DC power supplies
• Industrial automation systems
• Power electronics equipment
• OEM DC electrical panels
• Machinery DC circuits
• DC switchboards
• Renewable-energy electrical systems
• Control and auxiliary DC circuits
• Industrial infrastructure
• Electrical equipment protection
• Suitable medium-current DC installations

Benefits

The Siemens 5SL5225-7RC provides dependable circuit protection for DC applications requiring a 25 A, 2-pole MCB with C characteristic and 10 kA breaking capacity. Its dedicated DC design makes it suitable for applications where the interruption requirements are different from conventional AC circuit protection.

The 25 A rated current makes this MCB appropriate for suitably designed medium-current DC circuits. Correct selection of the protective-device rating helps ensure that cables, conductors and connected equipment are protected against excessive current while allowing normal operating current to flow without unwanted tripping.

The C tripping characteristic provides a practical option for compatible DC circuits where moderate starting or transient currents may occur. This can make the device suitable for selected control systems, DC equipment and industrial applications where the load characteristics match the selected tripping curve.

The 2-pole configuration provides coordinated protection and switching for compatible DC circuits. It can help panel builders create an organized protection arrangement in DC distribution boards, control panels, battery systems and OEM electrical assemblies.

The 10 kA breaking capacity provides a high specified short-circuit interruption capability for suitable DC installations. Since actual DC fault interruption depends on system voltage, wiring configuration and available fault current, the complete installation should be evaluated before selection.

The 440 V DC maximum operating voltage makes the 5SL5225-7RC suitable for selected higher-voltage DC applications within its specified operating conditions. This can include industrial DC distribution, energy systems, power electronics and other compatible applications.

The Siemens SENTRON 5SL5 DC series provides a dedicated modular solution for professional DC circuit protection. This makes the 5SL5225-7RC relevant for OEMs, panel builders, electrical contractors, automation integrators, battery-system designers and industrial maintenance teams.

For customers sourcing Siemens DC circuit protection products in Faridabad, Delhi NCR, Noida, Gurgaon/Gurugram, Ghaziabad, Punjab, Mumbai, Pune, Ahmedabad, Hyderabad, Bengaluru/Bangalore, Chennai, Kolkata, Jaipur, Chandigarh, Ludhiana and other major industrial and commercial locations across India, the 5SL5225-7RC can be considered for suitable applications.

Always verify the actual DC system voltage, polarity, pole connection, prospective short-circuit current and Siemens-approved wiring arrangement before installation.

Why Buy Siemens 5SL5225-7RC from SB Smart?

SB Smart supplies Siemens industrial electrical, automation and DC circuit protection products for OEMs, panel builders, electrical contractors, system integrators, energy-sector customers and industrial maintenance teams across India.

The Siemens 5SL5225-7RC 25A 2P C characteristic 10 kA DC MCB is suitable for customers looking for Siemens circuit protection products for industrial DC distribution, battery systems, control panels, power electronics, renewable-energy systems and OEM equipment.

SB Smart supports sourcing requirements across Faridabad, Delhi NCR, Noida, Gurgaon/Gurugram, Mumbai, Pune, Ahmedabad, Hyderabad, Bengaluru/Bangalore, Chennai, Kolkata, Chandigarh, Ludhiana and other major Indian industrial markets.

FAQs

1. What is Siemens 5SL5225-7RC?
It is a Siemens SENTRON 5SL5 DC miniature circuit breaker rated 25 A, 2-pole, C characteristic and 10 kA breaking capacity.

2. What is the rated current?
The rated current is 25 A.

3. Is the 5SL5225-7RC designed for DC applications?
Yes. It belongs to the Siemens 5SL5 DC MCB range and is intended for suitable DC circuit protection applications.

4. What is the maximum DC operating voltage?
The specified maximum operating voltage is 440 V DC.

5. What is the breaking capacity?
The specified short-circuit breaking capacity is 10 kA.

6. How many poles does this MCB have?
The 5SL5225-7RC is a 2-pole (2P) DC miniature circuit breaker.

7. Where can the Siemens 5SL5225-7RC be used?
It can be considered for suitable DC distribution systems, industrial control panels, battery applications, power electronics, OEM equipment and renewable-energy electrical systems.

8. Is the wiring arrangement important for this DC MCB?
Yes. Correct pole connection, polarity and wiring arrangement are important for proper DC fault interruption. The installation should follow the applicable Siemens connection instructions.
