The Siemens 3TF47020AP0ZA01WOKIT is a heavy-duty 3-pole power contactor from the 3TF SICOP series, designed for switching and controlling three-phase motors and industrial power loads. This variant is based on the standard 3TF47020AP0ZA01 configuration and features a 230V AC coil, 63A AC-3 rating, and 2NO + 2NC built-in auxiliary contacts. The "WOKIT" suffix typically indicates a supply/package variant without altering the core electrical characteristics.
• Siemens 3TF SICOP Series
• Model: 3TF47020AP0ZA01WOKIT
• Heavy-duty power contactor
• 3-pole design (3NO main contacts)
• 230V AC coil voltage
• Built-in 2NO + 2NC auxiliary contacts
• Rated current: 63A AC-3
• Motor rating: 30 kW at 415V AC
• Screw terminal connections
• Suitable for frequent motor switching applications
• High electrical and mechanical endurance
• Compatible with Siemens overload relays
• Industrial-grade construction for demanding environments
| Parameter | Specification |
|---|---|
| Manufacturer | Siemens |
| Series | 3TF SICOP |
| Part Number | 3TF47020AP0ZA01WOKIT |
| Product Type | Heavy Duty Power Contactor |
| Poles | 3 Pole |
| Main Contacts | 3NO |
| Coil Voltage | 230V AC |
| Frequency | 50 Hz |
| Rated Current (AC-3) | 63A |
| Motor Rating | 30 kW @ 415V AC |
| Auxiliary Contacts | 2NO + 2NC |
| Terminal Type | Screw Terminal |
| Mounting Style | Panel / DIN Rail Mount |
| Rated Insulation Voltage | 690V |
| Protection Class | IP20 |
| Frame Size | S3 |
| Standard | IS/IEC 60947-4-1, CE Marked |
