Thermal Overload Relay Accessory, 3UA Series, Variant G - 3UA68305G

Product Description

🔹 Siemens Thermal Overload Relay – 3UA68305G (3UA Series, Variant G)

🔹 Product Description

The Siemens 3UA68305G is a heavy-duty thermal overload relay from the Siemens 3UA Series, designed for high-current industrial motor protection applications. It provides reliable protection against overload, phase failure, and excessive temperature rise, ensuring safe operation of large motors in demanding industrial environments.

This G variant belongs to the 3UA6800 frame range, which is typically used for very high current motor applications in systems such as MCC panels, steel plants, cement industries, mining equipment, compressors, crushers, and large industrial drive systems.

The relay operates on a bimetal thermal inverse-time principle, where motor current generates heat through internal elements. When overheating occurs, the bimetal strips bend and trigger a trip mechanism, disconnecting the motor to prevent damage and equipment failure.

Based on Siemens 3UA design architecture, the 3UA68 series is intended for large industrial motors (hundreds of amps range) and is often used with CT-based sensing arrangements in heavy-duty electrical systems.

🔹 Key Features

• Genuine Siemens 3UA Series thermal overload relay
• Model: 3UA68305G
• G variant for ultra heavy-duty motor protection systems
• Designed for high-current industrial MCC applications
• Thermal bimetal overload protection technology
• Protection against overload and phase failure
• Suitable for large motors and industrial drive systems
• Inverse-time tripping for precise protection response
• High durability for continuous industrial operation
• Compatible with Siemens heavy-duty motor control assemblies
