The DPM96V310-2 Three-Phase LED Digital Voltage Meter is a high-precision instrument designed to measure and display three-phase AC voltage in industrial and commercial electrical systems. Built in a standard 96×96 mm panel size, this meter is ideal for installation in control panels, switchgear, and power distribution boards.
Equipped with a bright LED display, the meter ensures excellent visibility and clear readings even in low-light or harsh industrial environments. It provides real-time monitoring of voltage across all three phases, helping operators maintain system stability and prevent voltage imbalance or fluctuations.
Designed specifically for three-phase applications, the DPM96V310-2 is widely used in industries such as manufacturing, power plants, automation systems, and commercial infrastructure. It enables efficient monitoring of electrical parameters, ensuring safe and optimized performance of equipment like motors, generators, and transformers.
This digital panel meter is engineered with advanced electronics to deliver high accuracy, fast response, and stable performance. Its compact and durable design allows easy installation in standard panel cutouts, while the simple wiring configuration makes it convenient for electricians and technicians.
With minimal maintenance and long operational life, the DPM96V310-2 offers a reliable and cost-effective solution for continuous voltage monitoring in demanding environments.
| Parameter | Details |
|---|---|
| Model | DPM96V310-2 |
| Display Type | LED Digital Display |
| Measurement | AC Voltage (Three Phase) |
| Voltage Range | 0 – 500V AC (Typical) |
| System | Three Phase |
| Accuracy | ±0.5% of Full Scale |
| Display Size | 96 × 96 mm |
| Mounting | Panel Mount |
| Frequency | 50/60 Hz |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -10°C to 70°C |
| Protection Level | IP54 (Front Panel) |
