The Secure PT1 XX1-151 is a high-precision single-phase DC voltage transducer designed for accurate DC voltage measurement and analog signal conversion in industrial automation, process control, and power monitoring applications. Featuring Accuracy Class 0.5, it provides 2 galvanically isolated analog outputs (mA or Voltage) for seamless integration with PLCs, SCADA systems, DCS, and energy management systems. The transducer offers configurable input and output ranges, fast response time, DIN rail mounting, and Micro USB programming, making it ideal for industrial control panels, OEM equipment, and power distribution systems. It complies with IEC 60688 for reliable and accurate performance.
| Parameter | Specification |
|---|---|
| Brand | Secure |
| Model | PT1 XX1-151 |
| Product Type | DC Voltage Transducer |
| System | Single Phase |
| Measurement | DC Voltage |
| Accuracy Class | 0.5 |
| Analog Outputs | 2 Isolated Outputs |
| Output Type | Configurable (mA / Voltage) |
| Input Voltage | Configurable DC Voltage |
| Response Time | 100–220 ms |
| Mounting | DIN Rail (EN 50022) |
| Configuration | Micro USB with ConfigView Software |
| Protection | IP40 (Housing), IP20 (Terminals) |
| Operating Temperature | -5°C to +55°C |
| Standards | IEC 60688, IEC 61010-1, IEC 61010-2-30, IEC 61326-1 |
| Applications | PLC Panels, SCADA Systems, DCS, Process Control, Industrial Automation, Power Monitoring, Energy Management |
