The Secure PT1 XX1-151 is a high-precision single-phase DC voltage transducer designed for accurate DC voltage measurement and analog signal conversion in industrial automation and power monitoring applications. Featuring Accuracy Class 0.5, it provides reliable DC voltage measurement and 2 galvanically isolated analog outputs (mA or Voltage) for seamless integration with PLCs, SCADA systems, DCS, and control panels. Its compact DIN rail-mounted design, configurable input/output ranges, and fast response time make it an ideal solution for process automation, switchgear, OEM equipment, and energy management systems.
| Parameter | Specification |
|---|---|
| Brand | Secure |
| Model | PT1 XX1-151 |
| Product Type | DC Voltage Transducer |
| System | Single Phase |
| Measurement | DC Voltage |
| Accuracy Class | 0.5 |
| Analog Outputs | 2 Isolated Outputs |
| Output Type | Configurable (mA / Voltage) |
| Input Voltage | Configurable DC Voltage |
| Response Time | ≤100–220 ms |
| Mounting | DIN Rail (EN 50022) |
| Configuration | Micro USB with ConfigView Software |
| Protection | IP40 (Housing), IP20 (Terminals) |
| Operating Temperature | -5°C to +55°C |
| Standards | IEC 60688, IEC 61010-1, IEC 61010-2-30, IEC 61326-1 |
| Applications | PLC Panels, SCADA Systems, DCS, Industrial Automation, Process Control, Power Monitoring, Energy Management |
